Muenster, Germany – XIMEA, a pioneer in high speed interfaces, developed new models for the well established camera family of high resolution line cameras with PCI Express interface.
This PCIe high-speed camera line from XIMEA called xiB-64 already contains fast models ranging from 1 Mpix at 3600 Fps to 65 Mpix at 71 Fps.
The new models with names CB209, CB100 and CB024 offer resolutions up to 21 Megapixels at outstanding speeds of 300 frames per second.
The CB209 model utilizes color and mono versions of GSPRINT4521, the latest CMOS sensor from Gpixel which has picture parameters close to sCMOS quality.
The effective 5K resolution of this 21 Mpix Global shutter sensor contains 5120 x 4096 pixels with a size of 4.5 µm while still providing a dynamic range of 66 dB.
Next in line are models CB100 and CB024 equipped with GSPRINT4510 and GSPRINT4502 respectively offering 10 Mpix at 600 Fps and 2 Mpix at 3200 Fps.
Their 4K and 2K resolutions, like the one from CB209, are complemented by high Full well capacity of 30 000 e- and low Readout noise of around 3 e-.
There are several grades of GSPRINT4521, GSPRINT4510 and GSPRINT4502 sensors available.
Thus, XIMEA is capable to supply multiple camera versions to provide different levels of quality and prices. Including options with a Taped glass sensor.
These top tier sensors deserve an equally impressive interface and that high mark is met by PCI Express Gen3 x8 lanes delivering a bandwidth of 64 Gbits.
The real data throughput of 7000 MB/s is fully exercised with features like the 2x2 Binning or ROI (region of interest) to harness the sensor speed potential.
For overall heat dissipation reduction and even better noise results the cameras are equipped with a fan cooler which can be switched for a water cooling system.
Optional active EF-mount lens interface enables remote control of aperture, focus and image stabilization. All in a robust housing of 60 x 70 x 40 mm and 250 grams.
Additional benefits of PCIe interface are Direct memory access (DMA) with low CPU load and practically zero latency.
The cable can reach lengths above 100m using fiber optic and GPIO connectors ensure triggering and synchronization.
To summarize, the camera models expected to join the XIMEA portfolio have the following parameters:
2.4 Mpix, Gpixel GSPRINT4502, color and monochrome, 2048 × 1216 pixels, 2/3" with 2300 FPS
By using 2x2 Binning with 1024 x 608 resolution the speed can increase up to 10000 FPS
10 Mpix, Gpixel GSPRINT4510, color and monochrome, 4608 x 2176 pixels, 4/3" with 600 FPS
By using 2x2 Binning with 2 Mpix resolution the speed can increase to almost 2000 FPS
20.9 Mpix, Gpixel GSPRINT4521, color and monochrome, 5120 x 4096 pixels, APS-C with 300 FPS
By using 2x2 Binning with 5 Mpix the speed can increase above 1000 FPS
Applications examples include: Flat panel inspection, printed circuit board (PCB) examination, persistent stadium and border security, wide area surveillance, 360 panorama, cinematography, instant replays, Virtual and Augmented reality (VR, AR), Sports imaging and broadcasting, motion capture and aerial or city mapping.
Contact us for more information. We'll be happy to help.
