3D Step files and 2D drawings of PCIe Cameras¶

• 3D Step files and 2D drawings of PCIe Cameras
  • xiB
    • xiB camera models - 3D STEP and 2D Drawings
    • xiB camera accessories
  • xiB-64
    • xiB-64 camera models - 3D STEP and 2D Drawings
    • xiB-64 camera accessories
  • xiX
    • xiX camera models - 3D STEP and 2D Drawings
    • Pregius S Generation 4 Sony cameras
    • Pregius S Generation 4 Sony cameras full speed models
    • Ultraviolet camera model with Sony IMX487
    • Medium format Sony sensor camera models
    • xiX PCIe Gen3 x8 lane cameras - High resolution and speed
    • xiX camera accessories
    • xSwitches
    • Adapters

xiB¶

xiB camera models - 3D STEP and 2D Drawings¶

Models	3D step	2D Drawing
CB120xG-CM	CB120xG-CM	CB120xG-CM
CB200xG-CM	CB200xG-CM	CB200xG-CM
CB500xG-CM	CB500xG-CM	CB500xG-CM
CB500MG-CM-TG	CB500MG-CM-TG	CB500MG-CM-TG

xiB camera accessories¶

Part number	Description	3D model	2D Drawing	Manual
MECH-60MM-BRACKET-T	Tripod mounting bracket	CB-BRACKET	CB-BRACKET
MECH-60MM-HEATSINK	Heatsink for cooling	CB-HEATSINK	CB-HEATSINK
MECH-60MM-EF-ADAPTER-KIT	EF-mount adapter	EF-MOUNT	EF-MOUNT	Manual
LA-E-MNT-60MM-KIT	Sony E-mount adapter	E-MOUNT	E-MOUNT
XC-X4G3-MTP-X4G3-IPASS	iPass to MTP cable adapter	MTP converter	MTP converter	Manual
HA-1P-X4G3-MTP-X8G3	MTP single host adapter	MTP host adapter	MTP host adapter
HA-2P-X4G3-MTP-X8G3	MTP dual host adapter	MTP host adapter	MTP host adapter
XC-X4G3-SFF-X4G3-IPASS	iPass to SFF-8644 Gen3 x4 lanes	3D	Cable Converter	Manual
HA-2P-X4G3-SFF-X4G3	SFF-8644 dual host adapter x4	3D	SFF x4 host adapter	Manual
HA-2P-X4G3-SFF-X8G3	SFF-8644 dual host adapter x8	3D	SFF x8 host adapter	Manual

xiB-64¶

xiB-64 camera models - 3D STEP and 2D Drawings¶

Models	3D step	2D Drawing
CB013xG-LX-X8G3	CB013xG-LX-X8G3	CB013xG-LX-X8G3
CB019xG-LX-X8G3	CB019xG-LX-X8G3	CB019xG-LX-X8G3
CB024xG-LX-X8G3	CB024xG-LX-X8G3	CB024xG-LX-X8G3
CB100xG-LX-X8G3	CB100xG-LX-X8G3	CB100xG-LX-X8G3
CB120xG-CM-X8G3	CB120xG-CM-X8G3	CB120xG-CM-X8G3
CB160xG-LX-X8G3	CB160xG-LX-X8G3	CB160xG-LX-X8G3
CB209xG-GP-X8G3	CB209xG-GP-X8G3	CB209xG-GP-X8G3
CB262xG-GP-X8G3	CB262xG-GP-X8G3	CB262xG-GP-X8G3
CB654xG-GP-X8G3	CB654xG-GP-X8G3	CB654xG-GP-X8G3
CB654MG-GP-X8G3-TG	CB654MG-GP-X8G3-TG	CB654MG-GP-X8G3-TG

xiB-64 camera accessories¶

Part number	Description	3D model	2D Drawing	Manual
MECH-60MM-BRACKET-T	Tripod mounting bracket	CB-BRACKET	CB-BRACKET
CB-X8G3-FAN-COOLER-KIT	Fan/Cooler kit	CB-FAN	CB-FAN
CB-X8G3-WAT-COOLER-KIT	Liquid/Cooler kit	CB-WAT	CB-WAT
MECH-60MM-EF-ADAPTER-KIT	EF-mount adapter	EF-MOUNT	EF-MOUNT
LA-E-MNT-60MM-KIT	Sony E-mount adapter	E-MOUNT	E-MOUNT	Manual
LA-C-MNT-60MM	C-mount adapter	C-MOUNT	C-MOUNT
XC-X8G3-MTP-X8G3-IPASS	iPass to MTP cable adapter	MTP converter	MTP converter	Manual
HA-1P-X8G3-MTP-X8G3	MTP single host adapter	MTP host adapter	MTP host adapter
XC-X8G3-SFF-X8G3-IPASS	iPass to SFF-8644 Gen3 x8 lanes	3D	Cable Converter	Manual
HA-2P-X4G3-SFF-X8G3	SFF-8644 dual host adapter x8	3D	SFF x8 host adapter	Manual

xiX¶

xiX camera models - 3D STEP and 2D Drawings¶

Models	3D vertical	3D parallel	3D Firefly
MX022xG-CM	MX022xG-FV	MX022xG-FL	MX022xG-FF
MX023xG-SY	MX023xG-FV	MX023xG-FL	MX023xG-FF
MX031xG-SY	MX031xG-FV	MX031xG-FL	MX031xG-FF
MX042xG-CM	MX042xG-FV	MX042xG-FL	MX042xG-FF
MX042xR-GP-BSI	MX042BSI-FV
MX050xG-SY	MX050xG-FV	MX050xG-FL	MX050xG-FF
MX089xG-SY	MX089xG-FV	MX089xG-FL	MX089xG-FF
MX124xG-SY	MX124xG-FV	MX124xG-FL	MX124xG-FF
MX120xG-CM	MX120xG-FV	MX120xG-FL
MX200xG-CM	MX200xG-FV	MX200xG-FL
MX500xG-CM	MX500xG-FV	MX500xG-FL
MX500MG-CM-TG		MX500xG-TG-FL
MX262xG-GP-X8G3			MX262xG-FF
MX654xG-GP-X8G3			MX654xG-FF

Models	2D vertical	2D parallel	2D Firefly
MX022xG-CM	MX022xG-FV	MX022xG-FL	MX022xG-FF
MX023xG-SY	MX023xG-FV	MX023xG-FL	MX023xG-FF
MX031xG-SY	MX031xG-FV	MX031xG-FL	MX031xG-FF
MX042xG-CM	MX042xG-FV	MX042xG-FL	MX042xG-FF
MX042xR-GP-BSI	MX042BSI-FV
MX050xG-SY	MX050xG-FV	MX050xG-FL	MX050xG-FF
MX089xG-SY	MX089xG-FV	MX089xG-FL	MX089xG-FF
MX124xG-SY	MX124xG-FV	MX124xG-FL	MX124xG-FF
MX120xG-CM	MX120xG-FV	MX120xG-FL
MX200xG-CM	MX200xG-FV	MX200xG-FL
MX500xG-CM	MX500xG-FV	MX500xG-FL
MX500MG-CM-TG		MX500MG-TG-FL
MX262xG-GP-X8G3			MX262xG-FF
MX654xG-GP-X8G3			MX654xG-FF

Note: MX500 Sensor distance

Pregius S Generation 4 Sony cameras¶

2D Mechanical drawing

Model		Flex parallel		Flex perpendicular		Firefly
MX051		MX051xG-SY-X2G2-FL		MX051xG-SY--X2G2-FV		MX051xG-SY-X2G2-FF
MX081		MX081xG-SY-X2G2-FL		MX081xG-SY--X2G2-FV		MX081xG-SY-X2G2-FF
MX124		MX124xG-SY-X2G2-FL		MX124xG-SY--X2G2-FV		MX124xG-SY-X2G2-FF
MX161		MX161xG-SY-X2G2-FL		MX161xG-SY--X2G2-FV		MX161xG-SY-X2G2-FF
MX203		MX203xG-SY-X2G2-FL		MX203xG-SY--X2G2-FV		MX203xG-SY-X2G2-FF
MX245		MX245xG-SY-X2G2-FL		MX245xG-SY--X2G2-FV		MX245xG-SY-X2G2-FF

*Can be used for HDR models, for example: MX245MG-SY-X2G2-FL-HDR

3D Step files

Model		Flex parallel		Flex perpendicular		Firefly
MX051		MX051xG-SY-X2G2-FL		MX051xG-SY--X2G2-FV		MX051xG-SY-X2G2-FF
MX081		MX081xG-SY-X2G2-FL		MX081xG-SY--X2G2-FV		MX081xG-SY-X2G2-FF
MX124		MX124xG-SY-X2G2-FL		MX124xG-SY--X2G2-FV		MX124xG-SY-X2G2-FF
MX161		MX161xG-SY-X2G2-FL		MX161xG-SY-X2G2-FV		MX161xG-SY-X2G2-FF
MX203		MX203xG-SY-X2G2-FL		MX203xG-SY-X2G2-FV		MX203xG-SY-X2G2-FF
MX245		MX245xG-SY-X2G2-FL		MX245xG-SY-X2G2-FV		MX245xG-SY-X2G2-FF

*Can be used for HDR models, for example: MX161MG-SY-X2G2-FL-HDR

Pregius S Generation 4 Sony cameras full speed models¶

2D Mechanical drawing

Model		Default housing		With Air cooling		With water cooling	Overview
MX161		MX161xG-SY-X4G3-FF		MX161xG-SY--X4G3-FF		MX161xG-SY-X4G3-FF	MX161 Overview
MX203		MX203xG-SY-X4G3-FF		MX203xG-SY--X4G3-FF		MX203xG-SY-X4G3-FF	MX203 Overview
MX245		MX245xG-SY-X4G3-FF		MX245xG-SY--X4G3-FF		MX245xG-SY-X4G3-FF	MX245 Overview

3D Step files

Model		Default housing		With Air cooling		With water cooling
MX161		MX161xG-SY-X4G3-FF		MX161xG-SY-X4G3-FF		MX161xG-SY-X4G3-FF
MX203		MX203xG-SY-X4G3-FF		MX203xG-SY-X4G3-FF		MX203xG-SY-X4G3-FF
MX245		MX245xG-SY-X4G3-FF		MX245xG-SY-X4G3-FF		MX245xG-SY-X4G3-FF

Ultraviolet camera model with Sony IMX487¶

2D Mechanical drawing

Model		Flex line connector		Flex - vertical		Firefly connector	Overview
MX081		MX081UG-SY-X2G2-FL		MX081UG-SY-X2G2-FV		MX081UG-SY-X2G2-FF	MX081 Overview

3D Step files

Model		Flex line connector		Flex - vertical		Firefly connector
MX081		MX081UG-SY-X2G2-FL		MX081UG-SY-X2G2-FV		MX081UG-SY-X2G2-FF

Medium format Sony sensor camera models¶

2D Mechanical drawing

Model		Without Heatsink		With Air cooling		With water cooling		Accessories
MX610		MX610xG-SY-X4G3-FF		MX161xG-SY--X4G3-FF		MX610xG-SY-X4G3-FF		Diagram
MX1018		MX1018xG-SY-X4G3-FF		MX1018xG-SY--X4G3-FF		MX1018xG-SY-X4G3-FF		Diagram
MX1510		MX1510xG-SY-X4G3-FF		MX1510xG-SY--X4G3-FF		MX1510xG-SY-X4G3-FF		Diagram

3D Step files

Model		Without Heatsink		With Air cooling		With water cooling		MTP connector
MX610		MX610xG-SY-X4G3-FF		MX161xG-SY--X4G3-FF		MX610xG-SY-X4G3-FF		Fiber optic cable
MX1018		MX1018xG-SY-X4G3-FF		MX1018xG-SY--X4G3-FF		MX1018xG-SY-X4G3-FF		Fiber optic cable
MX1510		MX1510xG-SY-X4G3-FF		MX1510xG-SY--X4G3-FF		MX1510xG-SY-X4G3-FF		Fiber optic cable

xiX PCIe Gen3 x8 lane cameras - High resolution and speed¶

2D Mechanical drawing

Model		Without Heatsink		Accessories		Connections
MX262		MX262xG-GP-X8G3-FF		Diagram		FF, SFF, MTP
MX654		MX654xG-GP-X8G3-FF		Diagram		FF, SFF, MTP

3D Step files

Model		Without Heatsink
MX262		MX262xG-GP-X8G3-FF
MX654		MX654xG-GP-X8G3-FF

xiX camera accessories¶

Part number	Description	3D model	2D Drawing	Manual
MECH-60MM-BRACKET-T	Tripod mounting Big bracket	3D	2D
MECH-MC-BRACKET-T	Tripod mounting Small bracket	3D	2D
MECH-60MM-HEATSINK	Heatsink for cooling	3D	2D
ADPT-MX-MTP-FAN-COOLER	Mini Air Cooling module	3D	2D
ADPT-MX-MTP-WAT-COOLER	Mini Liquid Cooling module	3D	2D
MECH-60MM-EF-ADAPTER-KIT	EF-mount adapter	3D	2D
LA-E-MNT-60MM-KIT	Sony E-mount adapter	3D	2D	Manual
ME-LA-80MM-M72-L	M72-mount adapter	3D	2D
MX-ADAPTERS	Board adapter types	DIAGRAM	ADAPTER-TYPES
XEC-NX-3P-X2G3	NVIDIA Jetson NX carrier board	3D	2D	Manual
XEC2-4P-X2G2	NVIDIA Jetson TX2 carrier board	3D	2D
ADPT-MX-X4G3-FF-X4G3-MTP	Firefly to MTP Gen3 x4 lanes	3D	Converter attachment
ADPT-MX-X8G3-FF-X8G3-MTP	Firefly to MTP Gen3 x8 lanes	3D	Converter attachment
ADPT-MX-X4G3-FF-X4G3-SFF	Firefly to SFF-8644 Gen3 x4 lanes	3D	Converter attachment	Manual
ADPT-MX-X8G3-FF-X8G3-SFF	Firefly to SFF-8644 Gen3 x8 lanes	3D	Converter attachment	Manual
XC-X4G3-SFF-X4G3-IPASS	iPass to SFF-8644 Gen3 x4 lanes	3D	Cable Converter	Manual
XC-X4G3-MTP-X4G3-IPASS	iPass to MTP cable adapter	3D	MTP converter	Manual
XC-X8G3-SFF-X8G3-IPASS	iPass to SFF-8644 Gen3 x8 lanes	3D	Cable Converter	Manual
XC-X8G3-MTP-X8G3-IPASS	iPass to MTP cable adapter	3D	MTP converter	Manual
ADPT-1P-X4G3-FF-X4G3-MTP	For one PCIe Gen3 x4 camera	3D	Firefly to MTP adapter
ADPT-1P-X8G3-FF-X8G3-MTP	For one PCIe Gen3 x8 or two x4 cameras	3D	Firefly to MTP adapter
ADPT-2P-X2G3-FF-X4G3-MTP	For two PCIe Gen3 x2 cameras	3D	Firefly to MTP adapter
ADPT-4P-X2G3-FF-X8G3-MTP	For four PCIe Gen3 x2 cameras	3D	Firefly to MTP adapter
ADPT-1P-X4G3-FF-X4G3-SFF	For one PCIe Gen3 x4 Firefly camera	3D	Firefly to SFF-8644 adapter	Manual
ADPT-2P-X2G3-FF-X4G3-SFF	For two PCIe Gen3 x2 Firefly cameras	3D	Firefly to SFF-8644 adapter	Manual
HA-1P-X4G3-MTP-X8G3	MTP single host adapter x4	3D	MTP host adapter
HA-2P-X4G3-MTP-X8G3	MTP dual host adapter x4	3D	MTP host adapter
HA-1P-X8G3-MTP-X8G3	MTP single host adapter x8	3D	MTP host adapter
HA-2P-X4G3-FF-X8G3	Firefly dual host adapter x8	3D	Firefly host adapter
HA-2P-X4G3-SFF-X4G3	SFF-8644 dual host adapter x4	3D	SFF x4 host adapter	Manual
HA-2P-X4G3-SFF-X8G3	SFF-8644 dual host adapter x8	3D	SFF x8 host adapter	Manual

xSwitches¶

Part number	Description	3D step	2D Drawing
XS-4P-X2G2-X4G3	4 camera ports X2G2	3D file	2D Mechanical
XS-6P-X4G2-X8G3	6 ports X4G2, 4 ports X2G2, 4 USB3 ports	3D file	2D Mechanical
XS-12P-X2G2-X8G3	12 camera ports X2G2, 4 USB3 ports	3D file	2D Mechanical
XS-12P-X2G2-X8G3-SFF	12 camera ports X2G2, 4 USB3 ports, SFF output	3D file	2D Mechanical
XS-8P-X2G2-FF-X8G3	8 camera ports X2G2-FF (Firefly)	3D file	2D Mechanical
XS-8P-X2G2-FF-X8G3-MTP	8 camera ports X2G2-FF (Firefly), MTP output	3D file	2D Mechanical
HA-8P-X4G3-FF-X16G3	8 camera ports X4G3 (Firefly), Host adapter	3D file	2D Mechanical

Adapters¶

The whole compilation of the 3D step files for the adapters can be found HERE

Note: The tolerances are in accordance with the ISO2768-1 (fine).
This means that from 0-6mm the tolerance field is +/-0.05mm and from 6mm-100mm the tolerance field is +/-0.1mm.
